Description
| Video | |
| Image Sensor | 1/2.7” CMOS |
| Effective Pixel | 3200 (H) x 1800 (V) |
| Scanning System | Progressive |
| Min. Illumination | 0.001 Lux (F1.6, AGC ON), 0 LUX IR on |
| Lens | |
| Focal Length | 2.8 – 12mm (Varifocal Motorized Lens) |
| Angle of View | H : 109.5° – 34.3°, V : 59.2° ‐ 18.7°, D : 124.5° ‐ 39.1° |
| Distance Coverage (m) | 2.8mm { D : 63 m , O : 25.2 m , R : 12.6 m , I : 6.3 m |
| Electronic Shutter Speed | 12mm { D : 270 m O : 108 m , R : 43.2 m , I :27 m |
| Operational | |
| IR Distance | Up to 40 m |
| IR On/Off Control | Auto/manual |
| Smart IR | Support |
| Day/Night | IR‐cut filter with auto switch (ICR) |
| BLC Mode | BLC, HLC, Defog, True WDR (120 dB) |
| Smart alarm | N/A |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white
balance |
| IVD ‐ Advanse | Tampering alarm, Audio detection, Cross line (based on human body
detection), Intrusion (based on human body detection) |
| Noise Reduction | 2D/3D DNR |
| Motion Detection | Ultra motion detection (human/ vehicle detection) |
| Privacy Masking | Up to 4 Areas |
| Built‐in Mic | Support |
| Network | |
| Compression | Ultra 265, H.265, H.264, MJPEG |
| Audio | G.711U, G.711A, AAC‐LC |
| Multi Stream | Dual Stream |
|
Frame Rate |
Main Stream: 3200 × 1800 , 2560 × 1440 , 2304 × 1296 , 1920 × 1080 ,
1280 × 720 max. 30 fps; Sub Stream: 1280 × 720 , 720 × 576 , 640 × 360 , 704 × 288 , 352 × 288 , max. 30 fps; |
| Ethernet | 1 × RJ45 10 M/100 M Base‐TX |
| Storage | MicroSD card, Up to 512GB |
| Interoperability | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| Web Browser | Plug‐in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+,
Plug‐in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
|
Network Protocol |
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP,
HTTP, HTTPS, SMTP, SSL/TLS, QoS, SNMP, PPPoE, 802.1x |
| Audio Input | N/A |
| General | |
| Power Supply | DC 12V, PoE (IEEE 802.3af) |
| Ingress Protection | 4 Kv |
| Casing | Metal |
| Dimensions | 128.2 mm × 99.9 mm |
