Description
| Technical Specification | |
|
Ethernet Port |
1x Console |
| 8 x SFP+ 10Gbps | |
|
Network Media ( Cable ) |
1000BASE‐SX : 62.5um MMF (range: 2m~275m ) or 50um MMF ( range: 2m~550m ) 1000BASE‐LX : 62.5um/50um MMF (range: 2m~550m ) or 9um SMF ( range: 2m~5000m ) 10GBASE‐SR : OM1/OM2/OM3 or above MMF ( range: 2 m ~ 300 m )
10GBASE‐LR : IEC’s B1.1 and B1.3 SMF ( range: 2 m ~ 10,000 m ) |
| Transfer Method | Store and Forward |
| Switching Capacity | 160 Gbps |
| Packet Forwarding Rate | 119.04 Mbps |
| Packet Buffer Memory | 12 Mbit |
| MAC Table | 16 K |
| General | |
| Application Humidity | 5%~95% non‐condensing |
| Power | AC 100‐240V 50/60HZ |
| Storage Temperature | ‐40°C |
| Working Temperature | 0°C ‐ 45°C |
| Dimension(WxDxH) | 195 mm x 165 mm x 40 mm |
