Description
| Technical Specification | |
| CPU | Intel Core E3 |
| Operating System | Linux |
| Memory | 8GB DDR4 ECC |
| HDD | 3,5 Inch SATA Interface x 16 (Hot – Pluggable) |
| HDD Installation | Independent HDD Bracket |
| Capacity | Up to 256TB (Max 16TB per HDD) |
| RAID | Hardware Raid : Support RAID 0, 1, 5, 6 |
| Expansion | 1* PCI‐E3.0 x16 (x8) ; 1* PCI‐E3.0 x8 ; 1* PCE‐E3 x8 (x4) |
| Network Card | Integrated I210‐AT dual gigabit network cards, load balancing and if one is offline, the other will replace |
| IPMI | ASPEED AST2400 BMC, Independent IPMI interface, Support iKVM |
| Protocol | Support TCP / UDP / RTSP protocol |
| Search | Built in Index, accurate to second level |
| Performance | Up to 700 Mbps Incoming, 700Mbps Recording and 96 Mbps Playback
Up to 700 Mbps Incoming, 700Mbps Recording and 96 Mbps live View |
| Way of Management | WEB Management, seamless access to NVMS |
| Capability of Management | Raid Management, record management, system log as well as alarm processing |
| Max. number of Channel access | 2048 CH, Extensible to 10000CH via transfer server |
| Max. number of Device access | 500 devices, extensible to 10000CH after it authorized |
| Max. Channel access of single transfer service | 2048 CH |
| Max. Device access of single transfer service | 300 DVR/NVR or 500 IPCs |
| Max Decoding output number | 128 CH |
| Max transfer and storage server access | 32 |
| Max Channel and Device access or third party protocol | 16 Channels and 4 Devices (Both Extensible to 10000 CH after it authorized) |
| Max Channel of Simultaneous Preview and Playback | Preview : 100 ( For one Client/user ), Playback : 16 ( For one Client/user ) |
| Max number of views | Up to 64 view plans can be created |
| Max online users and user access | 64 user preview simultaneously , 64 user access (extensible up to 1024 users access after authorized) |
| Security | Supply TPM interfacre, TPM module installation supported |
| Interface | 1x VGA, 6x USB, 2x RJ45, 1x IPMI, 1x RS 232 |
| General | |
| Power | 550W 1+1 redundant power supply, 100~240V‐7~3.4A / 50~60hz |
| Working Temperature | ‐10°C ‐ 35°C Standby, ‐40°C ~ +55°C Ambient |
| Relative humidity & Noise | Working : < 90% RH (35°C), noise Working : < 50 Dba |
| Dimension(WxDxH) | 444 mm x 670 mm x 132 mm |
