Description
| Video | |
| Image Sensor | 1/2.7” CMOS |
| Effective Pixels | 2880 (H) x 1620 (V) |
| Scanning System | Progressive |
| Min illumination | 0.003 Lux (F1.2, AGC On), 0 Lux with IR |
| Lens | |
| Focal Length | 2.7 – 13.5mm |
| Optical Zoom | 5X |
| Angle Of View | ( H ) : 104.9° – 30.6° , ( V ) : 55.4° – 17.7° , ( D ) : 129.0° – 39.8° |
| Electronic Shutter Speed | Auto/Manual, 1 – 1/100000 s |
| Distance Coverage (m)
Pan/tilt Range |
D : 247.5m , O : 99m , R : 49.5m , I : 24.8m |
| Pan : 350° , Tilt : 0° – 90° | |
| Manual Control Speed | Pan : 0.1°/s – 60°/s , Tilt : 0.1° – 50°/s |
| PTZ Mode | 16 patrols, up to 64 presets for each patrol |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Auto Tracking | Support |
| Operational | |
| IR Distance | Up to 30m |
| Smart IR | Support |
| Day / Night | IR-cut filter with auto switch (ICR) |
| Backlight Compensation | HLC, BLC, Digital Defog, WDR (120dB) |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Noise Reduction
Motion Detection |
2D/3D DNR |
| Support | |
|
Intelligent Advance |
Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human,
non-motor vehicle and vehicle) |
| Privacy Masking | 24 areas, up to 4 areas per scene |
| Network | |
| Compression Audio
Multi Streams |
Ultra 265, H.265, H.264, MJPEG |
| G711 A/U | |
| Triple Streams | |
|
Frame Rate |
Main Stream: 5 MP (2880 × 1620), max. 30 fps; |
| Sub Stream: 720P (1280 × 720), max. 30 fps; | |
| Third Stream: D1 (720 × 576), max. 30 fps | |
| Ethernet | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Interoperability | ONVIF , API, SDK |
| Edge Storage | Micro SD card Up to 512GB |
|
Protocol |
SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x,
SNMP, QoS, SSL/TLS |
| Web Viewer | IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| RS485 | 1/1 |
| Alarm I/O | 1/1 |
| General | |
| Power Supply | DC 12V, PoE+ ( 802.3at ), 18W |
| Operating conditions | -10°C – 50°C |
| Operating Humidity
Dimensions |
≤ 95% RH Non-Condensing |
| 129 mm × 143.6 mm | |
| Gross Weight | 780g |
