Description
| Technical Specification | |
|
Ethernet Port |
8*10/100 Mbps RJ‐45, PoE AF/AT
2*10/100 Mbps RJ‐45 2*1000 Mbps SFP |
| PoE Power Consumption | Port 1‐8, Total power ≤ 96 Watt |
| PoE Protocol
Total Power |
IEEE802.3af (PoE), IEEE802.3at (PoE+) |
| ≤ 96W | |
| Switching Capacity | 9,6Gbps |
| Packet Forwarding Rate | 16,37 Mpps |
| Packet Buffer Memory | 7,14 Mbit |
| MAC Table | 2K |
|
Network Medium |
10 base‐T, UTP cat 5, 6 ( Max‐100m )
100 base – Tx, UTP cat 5,6 ( Max‐100m ) 1000 base‐T, UTP cat 5e, 6 ( Max‐100m ) 10000 base‐x MMF, SWF |
| General | |
| Application Humidity | 10% ‐ 90% |
| Power | AC:100‐240V, 50/60Hz |
| Lighting Protection | Common Mode 6KV |
| Working Temperature | ‐30°C ‐ 65°C |
| Weight | 0,62Kg |
| Dimension(WxDxH) | 200mm × 119mm × 45mm |
